Power System
Roto-Screen's
power is a rugged, dependable and economical diesel work horse, made by DEUTZ.
This sturdy motor is specially designed
to withstand the dustiest of condititons. Its Air Cooled engine assures low maintenance.
The DEUTZ F4L912, a 4
cylinder Air Cooled Engine rated at 65hp, with one of the best fuel consumption in its class. Its carefully developed combustion
process offers the best combination of excellent exhaust gas performance and low fuel consumption, that meets todays Severe
emission laws around the world (EPA, CARB, EURO). Equiped with emergency shut down system.
We listened to customers
and improved it for the 21st Century.
New Upgrades for the New Millennium,
* Top soil
* Sand
* Gravel
* Manure
* Land clearning
debris
* Asphalt
* Urban compact garbage
* Woodchips
* Soil- sand mixing
Technical Data
Length ............................ 42'0"
Width .............................
102"
Weight ............................ 8500 kg
17000
lbs
Height ......................... (travel) 13'4"
(work) 14'0"
Work mode:
Height of feeder bin ............................ 13'1"
Width of discharge conveyor ................. 48"
Capacity of feeder .............................. 6 cubic yards,
8 cubic yards,
heaped
Width of feeder conveyor ..................... 30"
Diameter of screening cylinder ............... 5'0"
int.
Length of cylinder ............................... 12'
Screening surface ...............................
135 square feet
